High Flux thin-flim composite membrane element for the purification of Ultrafiltration permeate from Electrocoat Paint.
A specially designed thin-film composite membrane separates the aqueous phase of the UF permeate from its residual resins and dissolved ions. This high flux element provides greater productivity, good throughput, and excellent permeate clarity.
Proprietary thin-film composite membrane provides excellent rejection of resins and dissolved solids while providing outstanding flux rates.
Element construction for rugged durability, high flux rates, and long life.
Purification of UF Electrocoat Paint permeate for use as one of the final rinse solutions.
Available in standard diameters and lengths to fit most housings for use either in a series or in parallel, as well as custom designed configurations for maximum performance and optimal cleaning.
Membrane: Thin-film composite (Polyamide over polysulfone)
Support Layers: Polyester
Structure: Polysulfone
Outer Wrap: Fiber Glass/Epoxy
Special element construction available for higher recovery and lower tangential flow resistance
Available in standard EP and RO product configurations
Maximum inlet pressure*: 250 psi (17.2 bar)
Typical inlet pressure*: 100 psi (6.9 bar)
Max. operating temperature: 122ºF (50ºC)
pH Range, continuous: 3 – 10
pH Range, short term: 2 – 11 122ºF
Cleaning Agents: Consult Factory
